【資料成文時(shí)間】：2007
【語言】：英文
【頁(yè)數(shù)】：軟件
【何人（公司）所著】：ERICSSON
【文件格式】：EXE
【文件原名】：ERICSSON OMT R32_6
【摘要或目錄】：OMT Version: R32_6
1Release Notes
1.1R32_6
1.2R31_9
1.3R31_6
1.4R30_4
1.5R29_3
1.6R28_2
1.7R26_5
1.8R23_9
1.9R23_5
1.10R23_2
1.11R22_3
1.12R21_3
1.13R20
1.14R19_1
1.15R17_5
1.16R17_4
1.17R14_3
1.18R14_1
1.19R12
2Limitations
3System software and hardware requirements
3.1System software requirements
3.2Hardware requirements
4Installing the OMT software
1Release Notes
1.1R32_6
1.1.1New Configurations
•RBS 29x4 Support (Same configurations as RBS 2216).
•RBS 2216 GSM 900 and GSM 1800



oSingle band uncombined configurations:
1x2, 1x4, 1x6, 1+1, 1+1+2, 2x2, 2+1+1, 2+3+3, 2+2+4, 2+4+2, 2+4+4, 3x2, 3x4, 3+3+2, 4+2+2, 4+2+4, 4+4+2with and without TMA in all sectors independently
2+4, 2+6, 2+2+4, 3+3+4 with optional TMA in first sectors and with or without TMA in last sector
4+2, 6+2, 4+2+2, 4+3+3 with or without TMA in first sector and optional TMA in other sectors
2+4+2 with or without TMA in second sector, and optional TMA in other sectors
2+4+4 with optional TMA in first sector and with or without TMA in other sectors
4+2+4 with optional TMA in second sector and with or without TMA in other sectors
4+4+2 with optional TMA in third sector and with or without TMA in other sectors
2x4, 4+6, 6+4, 3x4 without TMA in any sector
2x4, 4+6, 6+4, 2x6, 3x4 with TMA in all sectors
2x4, 4+6, 6+4, 2x6, 3x4 with TMA in first sector and without TMA in other sectors
3x4 with and without TMA in first and third sector and with TMA in second sector
2x4, 4+6, 6+4, 2x6, 3x4 without TMA in first sectors and with TMA in last sector
3x4 with TMA in first sectors and without TMA in last sector
3x4 without TMA in first sector and with TMA in other sectors
oSingle band uncombined splitter configurations:
1x4, 1x6, 2x4, 2x6, 2+4, 2+6, 2+2+4, 2+3+3, 2+4+2, 2+4+4, 3x4, 3+3+2, 3+3+4, 4+2, 4+6, 4+2+2, 4+2+4, 4+4+2, 4+3+3, 6+2, 6+4 with and without TMA in all sectors independently
4+6 without TMA in first sector and optional TMA in second sector
4+6 with TMA in first sector and optional TMA in second sector
oSingle band combined configuration with and without TMA in all sectors independently:
1x2, 1x4, 1x6, 1x8, 1x10, 1x12, 2x2, 2x4, 2x6, 2+4, 2+6, 2+8, 2+2+4, 2+4+2, 2+4+4, 3x2, 3x4, 4+2, 4+6, 4+8, 4+2+2, 4+2+4, 4+4+2, 6+2, 6+4, 8+2, 8+4
oSingle band combined splitter configuration with and without TMA in all sectors independently:
1x2, 1x4, 1x6, 1x8, 1x10, 1x12, 2x4, 2x6, 2+4, 2+6, 2+8, 2+2+4, 2+4+2, 2+4+4, 3x4, 4+2, 4+6, 4+8, 4+2+2, 4+2+4, 4+4+2, 6+2, 6+4, 8+2, 8+4
oSingle band configuration mix of combined and uncombined with and without TMA in all sectors independently:
2+3+3, 3+3+2, 3+3+4, 4+3+3
oSingle band splitter configuration mix of combined and uncombined with and without TMA in all sectors independently:
2+3+3, 3+3+2, 3+3+4, 4+3+3
oSingle band 4-way receiver diversity configurations with TMA:
1x4, 2x4, 3x4
oSingle band 4-way receiver diversity splitter configurations with TMA:
1x2, 2x2, 2+2+4, 2+4+2, 2+4+4, 3x2, 4+2+2, 4+2+4, 4+4+2
oSingle band RX antenna sharing configurations with TMA:
4+8
oDual band uncombined configurations:
1+1+2, 2x2, 2+1+1, 2+3+3, 2+2+4, 2+4+2, 2+4+4, 3x2, 3x4, 3+3+2, 4+2+2, 4+2+4, 4+4+2, 2x2|2x2, 3x2|3x2with and without TMA in all sectors independently
2+4, 2+6, 2+2+4, 3+3+4 with optional TMA in first sectors and with or without TMA in last sector
4+2, 6+2, 4+2+2, 4+3+3 with or without TMA in first sector and optional TMA in other sectors
2+4+2 with or without TMA in second sector, and optional TMA in other sectors
2+4+4 with optional TMA in first sector and with or without TMA in other sectors
4+2+4 with optional TMA in second sector and with or without TMA in other sectors
4+4+2 with optional TMA in third sector and with or without TMA in other sectors
2x4, 4+6, 6+4, 3x4 without TMA in any sector
2x4, 4+6, 6+4, 2x6, 3x4 with TMA in all sectors
2x4, 4+6, 6+4, 2x6, 3x4 with TMA in first sector and without TMA in other sectors
3x4 with and without TMA in first and third sector and with TMA in second sector
2x4, 4+6, 6+4, 2x6, 3x4 without TMA in first sectors and with TMA in last sector
3x4 with TMA in first sectors and without TMA in last sector
3x4 without TMA in first sector and with TMA in other sectors
2x4|2x2 with and without TMA in first and third sector and optional TMA in other sectors
2x4|2x2 with TMA in first sector, without TMA in third sector and optional TMA in other sectors
2x4|2x2 without TMA in first sector, with TMA in third sector and optional TMA in other sectors

oDual band uncombined splitter configurations:
2x4, 2x6, 2+4, 2+6, 2+2+4, 2+3+3, 2+4+2, 2+4+4, 3x4, 3+3+2, 3+3+4, 4+2, 4+6, 4+2+2, 4+2+4, 4+4+2, 4+3+3, 6+2, 6+4, 2x4|2x2, 1+1+2|1+1+2, 3x2|1+1+2 with and without TMA in all sectors independently
4+6 without TMA in first sector and optional TMA in second sector
4+6 with TMA in first sector and optional TMA in second sector
oDual band combined configuration with and without TMA in all sectors independently:
2x2, 2x4, 2x6, 2+4, 2+6, 2+8, 2+2+4, 2+4+2, 2+4+4, 3x2, 3x4, 4+2, 4+6, 4+8, 4+2+2, 4+2+4, 4+4+2, 6+2, 6+4, 8+2, 8+4, 2x2|2x2, 2x4|2x2, 3x2|3x2
oDual band combined splitter configuration with and without TMA in all sectors independently:
2x4, 2x6, 2+4, 2+6, 2+8, 2+2+4, 2+4+2, 2+4+4, 3x4, 4+2, 4+6, 4+8, 4+2+2, 4+2+4, 4+4+2, 6+2, 6+4, 8+2, 8+4, 2x4|2x2
oDual band configuration mix of combined and uncombined with and without TMA in all sectors independently:
2+3+3, 3+3+2, 3+3+4, 4+3+3
oDual band splitter configuration mix of combined and uncombined with and without TMA in all sectors independently:
2+3+3, 3+3+2, 3+3+4, 4+3+3
•RBS 2206V2 Support (Same configurations as RBS 2206).
•RBS 2111 GSM1800.
oSingle band uncombined configurations:
1x2, 2x2, and 3x2

oSingle band combined configurations:
1x4 and 1x6

oDual band uncombined configurations:
1x2 + 1x2, 1x2 + 2x2 and 2x2 + 1x2
1.1.2Modified views
•Display OMT version and RBS type in System View
•Radio view:
oRadio paths inside ASU/CXU/HCU/SPLITTER.
oTool tip on connection points with port names.
•Show Antenna System in Radio view as defined
•Show Cable info in Radio view
•Show Current Injectors in Radio View
•Filter Cables in Radio View
1.1.3New functions
•RF Cable Supervision in 2216 configurations
•OMT Improvements
oRemain in same OMT view as defined
•Display RX/TX Antenna Mapping.
•Enable EdTRU in RBS 2106
